LPJD4012BENL, Vertical RJ45 Jack, 1CT: 1CT, 8P8C 10 / 100Mbps, Perisai LED G-Y

Name: LPJD4012BENL, Vertical RJ45 Jack, 1CT: 1CT, 8P8C 10 / 100Mbps, Perisai LED G-Y
Brand: LINK-PP INT'L TECHNOLOGY CO., LIMITED
SKU: LPJD4012BENL
Price: 0.09 USD
Availability: InStock

Rincian Produk

Tempat asal: Guangdong, Cina

Nama merek: LINK-PP

Sertifikasi: UL,ROHS,Reach,ISO

Nomor model: LPJD4012BENL

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order: 50/500/1000/25K

Harga: $0.09-$1.85

Kemasan rincian: 60pcs/Tray22 nampan/karton, Size37 * 30 * 30 cm, 10KGS (1320pcs)

Waktu pengiriman: persediaan

Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day

Menyediakan kemampuan: 3000000/bulan

Dapatkan Harga Terbaik

Rincian Produk

Deskripsi Produk

Menyoroti:
                                                                                                                                                                                    100Base-T Vertikal RJ45 Jack, 8P8C RJ45 vertikal


Jenis:	Konektor RJ45 Vertikal Dengan Magnet Terintegrasi	Memalangi:	Di atas.
Ethernet:	10/100Base-T Ethernet PHY	Lampu indikator:	Hijau kuning
Orientasi:	180 Derajat	Tipe pemasangan:	Melalui Lubang

Jenis:	Konektor RJ45 Vertikal Dengan Magnet Terintegrasi
Memalangi:	Di atas.
Ethernet:	10/100Base-T Ethernet PHY
Lampu indikator:	Hijau kuning
Orientasi:	180 Derajat
Tipe pemasangan:	Melalui Lubang

LPJD4012BENL, Vertical RJ45 Jack, 1CT: 1CT, 8P8C 10 / 100Mbps, Perisai LED G-Y

LPJD4012BENL, Vertikal RJ45 Jack, 1CT:1CT, 8P8C 10/100Mbps, Shield LED G-Y

LPJD4012BENL
Top Entry Rj-45 Model
Rj45 Dengan Magnetik Terintegrasi
1x10/100Mbps Konektor Rj45 Vertikal
8P8C Perisai Rj45 lurus dengan LED
LPJD4012BENL.pdf

Catatan Uji ((25±5°C)
1.TR: ((100KHz,0.1V);
TX=1CT:1CT

RX=1CT:1CT

2.LX: ((100KHz,100mV,8mA, DC Bias)
PINS: ((P1-P3), ((P4-P6) = 350uH MIN
3. Transmitter Filter & Receiver Filter Jenis:
Impedansi low pass 100Ω
4Hipotesis:
Input ((P1-P3)TO Output ((J1-J2):1500VAC 60detik
Input ((P4-P6) TO Output ((J3-J6):1500VAC 60detik
5. Rugi penyisipan:
-1.0dB MAX @ 1.0MHz TO 100MHz
6Kembali kehilangan:
-18dB MIN @ 1.0MHz TO 30MHz
-16dB MIN @ 30MHz TO 60MHz
-12dB MIN @ 60MHz TO 80MHz
7- Bicara Silang:
-30dB MIN @1.0MHz TO 100MHz
8. MEMBANTING MODE KOMUN:
-30dB MIN @1.0MHz TO 100MHz
9. Suhu operasi: -40°C+85°C.
