Rincian Produk
Tempat asal: Cina
Nama merek: LINK-PP
Sertifikasi: UL,ROHS,Reach,ISO
Nomor model: HFJ11-1G02E-L12V3RL
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 50/500/1000
Harga: Supportive
Kemasan rincian: 50PCS / Baki, 1200pcs / Carton
Waktu pengiriman: persediaan
Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day
Menyediakan kemampuan: 4600K. PCS/bulan
PN: |
HFJ11-1G02E-L12V3RL |
Halo PN: |
HFJ11-1G02E-L12V3RL |
Buatan China: |
LINK-PP LPJG0805GENL |
Aplikasi: |
100/1000 Base-TX, AutoMDIX |
Keluarga: |
Magnetics Rj45 jack |
Orientasi: |
Sudut 90 ° (kanan) |
Warna LED: |
Hijau kuning |
Pemasangan: |
Melalui lubang |
PN: |
HFJ11-1G02E-L12V3RL |
Halo PN: |
HFJ11-1G02E-L12V3RL |
Buatan China: |
LINK-PP LPJG0805GENL |
Aplikasi: |
100/1000 Base-TX, AutoMDIX |
Keluarga: |
Magnetics Rj45 jack |
Orientasi: |
Sudut 90 ° (kanan) |
Warna LED: |
Hijau kuning |
Pemasangan: |
Melalui lubang |
HFJ11-1G02E-L12V3RL = LPJG0805GENL | ||||||||||||||||||||||||||||||||
| Nomor Bagian Pedagang | HFJ11-1G02E-L12V3RL Halo |
| ||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pabrikan | Lingkaran cahaya | |||||||||||||||||||||||||||||||
| Produsen PN | HFJ11-1G02E-L12V3RL | |||||||||||||||||||||||||||||||
| Deskripsi | 10/100 / 1000Mbps Magjack Rj45 | |||||||||||||||||||||||||||||||
| Status Bebas Timbal / Status RoHS | Bebas timah / Sesuai RoHS | |||||||||||||||||||||||||||||||
| LINK-PP China Factory Cross | LPJG0805GENL Buatan China | |||||||||||||||||||||||||||||||
| LPJG0805GENL Kuantitas Tersedia | 2.000 PCS | |||||||||||||||||||||||||||||||
LINK-PP Buatan China, Daftar Produksi Massal Pabrik:
| MIC24013-5104T-LF3 | 74990112121 | 13F-64YGD2PLNW2NL | HFJ11-1G02E-L12V3RL |
| 99751813-01 | 74990112121 | XFATM2GA-CLGY1-2MS | XFATM6CB-CLYG1-4MS |
| JX0011D21BNL | J00-0045NL | MTJ-88TX1-FSZ-PG-D1LH-M7 | MIC24013-5104T-LF3 |
| RJLD260TC1 | SI-60118-F | HFJ11-E2450E-L12RL | 74990112121 |
| RJLD-260TC1 | J1B1211CFD | XFATM2E-Clxu1-4MS | HFJ11-1G02E-L12V3RL |
| 213A-11XAX-R | RJC-248TC1 | MIC24013-5104T-LF3 | MIC66011-5171T-LF3 |
| JXR0-0015NL | RJLBC-060TC1 | HFJ11-1G02E-L12V3RL | XFO656P-CLxu1-4MS |
| 13F-64HND2NL | HY911105AE | 5-1840450-7 | 24F-2011EGYD2SNWXNL |
| HFJ11-E2450E-RL | 2-1840450-8 | HFJ11-E2450E-L11RL | 5-6605443-1 |
| SJTAB-40LB02-L | RJLB-001TC1 | 13F-64GYDPNS2NL | XFAMT6SA-CLGY1-4MS |
| 3070-110204 | J00-0045NL | HFJ11-1G02E-L12V3RL | 24G-66JGYDPLZ2NL |
| 74990112121 | 74990112121 | MIC24013-5104T-LF3 | HFJ11-1G02E-L12V3RL |
HFJ11-1G02E-L12V3RL SPESFIKASI LISTRIK: @ 25 ℃
SPESFIKASI LISTRIK @ 25 ℃
1. Rasio Putaran (%% P2%):
1CT: 1CT
2. Induktansi OCL: 350uH MIN
@ 100KHz / 0.1V, 8mA DC Bias
3. Rugi Insersi:
-1.1dB MAKS @ 0.1-100MHz
4. Rugi Kembali:
-18dB MIN @ 1-40MHz
-14.5dB MIN @ 60MHz
-12dB MIN @ 80MHz
-10dB MIN @ 100MHz
5. Bicara silang:
-40dB MIN @ 1-30MHz
-35dB MIN @ 30-60MHz
-30dB MIN @ 60-100MHz
6. Penolakan Mode Umum:
-40dB TYP @ 0,1-100MHz
7. Tes Hipot: 1500Vrms
8. Suhu Operasi: 0 ℃ TO 70 ℃. / -40 ℃ TO + 85 ℃
