Rincian Produk
Tempat asal: Cina
Nama merek: LINK-PP
Sertifikasi: UL,ROHS,Reach,ISO
Nomor model: ARJ11C-MBSAT-A-B-3MU2
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 50/500/1000
Harga: Supportive
Kemasan rincian: 50PCS / Baki, 1200pcs / Carton
Waktu pengiriman: persediaan
Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day
Menyediakan kemampuan: 4600K. PCS/bulan
Nomor bagian: |
ARJ11C-MBSAT-A-B-3MU2 |
LED: |
UP |
Munafactuer asli: |
LINK-PP |
Ethernet: |
10/100/1000 cepat |
Keluarga: |
PCB 10pin RJ45 |
Mengetik: |
Jack magnetik RJ45 |
Nomor bagian: |
ARJ11C-MBSAT-A-B-3MU2 |
LED: |
UP |
Munafactuer asli: |
LINK-PP |
Ethernet: |
10/100/1000 cepat |
Keluarga: |
PCB 10pin RJ45 |
Mengetik: |
Jack magnetik RJ45 |
| ARJ11C-MBSAT-AB-3MU2 | Jack RJ45 Magnetik | 10/100/1000 Base-T | Konektor Rj45 Lekukan |
SPESIFIKASI LISTRIK: @ 25 ℃
ARJ11C-MBSAT-AB-3MU2 Harga / PDF / Spesifikasi / Salib.
1.Turns Ratio (± 2%):
TX = 1CT: 1CT
RX = 1CT: 1CT
2.Persiapan kerugian:
0.1-0.9MHz: -1.0dB Max 0.9-100MHz: -1.1dB Max
3.Return Loss (dB Min):
0,1-15MHz: -18
15-60MHz: -16
60-80MHz: -15
80-100MHz: -12
4.Crosstalk (dB Min):
0,1-0,9MHz: -43 1-15MHz: -35 15-30MHz: -26 30-100MHz: -24
5.CMR (dB Min):
0,1-30MHz: -46 30-100MHz: -42
6.Isolation Voltage: 1500Vrms
7. Kisaran Suhu Operasi: 0 ℃ UNTUK 70 ℃ / -40 ℃ Untuk 85 ℃
CATATAN:
1.Dirancang untuk mendukung aplikasi, seperti SOHO (ADSL
modem), LAN-on-Motherboard (LOM), hub dan Switch.
2.Memenuhi spesifikasi IEEE 802.3
3. Bahan Bahan:
Perumahan: Termoplastik UL94V-0
Kontak / Perisai: Paduan tembaga
Perisai plating: Nikel
Kontak plating: Emas 6 inci mikro. Di area kontak.
4.Wave suhu ujung solder: 265 ℃ Max
Suhu ujung solder ujung gelombang: 5 Detik Maks
