Rincian Produk
Tempat asal: Cina
Nama merek: LINK-PP
Sertifikasi: UL,ROHS,Reach,ISO
Nomor model: ARJC02-111009D
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 50/500/1000
Harga: Supportive
Kemasan rincian: 50PCS / Baki, 1200pcs / Carton
Waktu pengiriman: Saham
Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day
Menyediakan kemampuan: 4600K. PCS/bulan
SPEC: |
ARJC02-111009D |
Aplikasi: |
10/100 Base-T, AutoMDIX |
Perbarui.PN: |
LPJ0011BBNL |
Aplikasi: |
Solusi Jaringan Cepat |
Sampel: |
Gratis |
LED: |
hijau kuning |
SPEC: |
ARJC02-111009D |
Aplikasi: |
10/100 Base-T, AutoMDIX |
Perbarui.PN: |
LPJ0011BBNL |
Aplikasi: |
Solusi Jaringan Cepat |
Sampel: |
Gratis |
LED: |
hijau kuning |
| Abracon ARJC02-111009D | Pabrikan. LPJ0011BBNL | 10 / 100B Rj45 | Salib / PDF / Harga / 3D |
• Compliant dengan standar IEEE802.3
• OCR minimum 350uH dengan arus bias 8mA
• Kinerja tinggi untuk penekanan EMI maksimum
• Keandalan tinggi - 750 siklus kawin / unmating
• Dirancang untuk sebagian besar produsen PHY IC terkemuka seperti Broadcom,
Marvell, Microsemi.
• Mendukung 10/100 Base-Tapplications
• Menyediakan pengkondisian sinyal, penekanan EMI dan isolasi sinyal.
• Kisaran suhu pengoperasian: 0ºC hingga +70ºC
• Kisaran suhu penyimpanan: -25ºC hingga + 85ºC
• Stok Tersedia dibeli Termurah
SPESIFIKASI LISTRIK: @ 25 ℃
1.Turn Ratio (%% P2%):
TX = 1CT∶1CT RX = 1CT∶1CT
2.Inductance OCL: 350uH MIN
@ 100KHz 0.1V 8mA DC Bias
Kerugian 3.Insion:
-1.0dB MAX @ 1.0-100MHz
4.Return Loss:
-18dB MIN @ 1-30MHz
-15dB MIN @ 30-60MHz
-12dB MIN @ 60-80MHz
-10dB MIN @ 80-100MHz
5.Cross talk:
-40dB MIN @ 30MHz
-35dB MIN @ 60MHz
-30dB MIN @ 100MHz
6. Penolakan Mode Umum:
-40dB MIN @ 30MHz
-35dB MIN @ 60MHz
-30dB MIN @ 100MHz
7.Hipot: 1500Vrms
8. Rentang Suhu Operasi: -40 ℃ KE + 85 ℃
CATATAN:
1.Dirancang untuk mendukung aplikasi, seperti SOHO (ADSL
modem), LAN-on-Motherboard (LOM), hub dan Switch.
2.Memenuhi spesifikasi IEEE 802.3
3. Bahan Bahan:
Perumahan: PBT Termoplastik + 30% GF UL94V-0
Kontak: Phosphor Bonze C5210R-EH Tebal = 0,35mm
Pin: Brass C2680R-H Tebal = 0.35mm
Shield: SUS 201-1 / 2H Tebal = 0.2mm
Kontak plating: Emas 6 inci mikro. Di area kontak.
4.Wave suhu ujung solder: 265 ℃ Max, 5 Sec Max
| ARJC02-111009D, Magnetic RJ45 Jack 10/100 Base-Tx Tap Bawah RJ45 W / LED | ||
|---|---|---|
