Rincian Produk
Tempat asal: Guangdong, Cina
Nama merek: LINK-PP
Sertifikasi: UL,RoHS,Reach,ISO
Nomor model: 749020010A
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 400/2000/10K/25K
Harga: $0.06-$3.2
Kemasan rincian: T&R
Waktu pengiriman: persediaan
Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day
Menyediakan kemampuan: 3KK/Bulan
Spesifikasi: |
749020010A |
Transformer Type: |
Isolasi dan Data antarmuka |
Ternyata Ratio - Primer: Secondary: |
1: 1 Transmitter, 1: 1 Receiver |
Jenis mounting: |
Permukaan gunung |
Ukuran / Dimensi: |
13.97mm L x16.51mm W |
Tinggi - duduk (Max): |
6.25 mm |
Archivi Disponibil: |
PDF / 3D / ISG / Stp / Langkah / Datasheet |
Spesifikasi: |
749020010A |
Transformer Type: |
Isolasi dan Data antarmuka |
Ternyata Ratio - Primer: Secondary: |
1: 1 Transmitter, 1: 1 Receiver |
Jenis mounting: |
Permukaan gunung |
Ukuran / Dimensi: |
13.97mm L x16.51mm W |
Tinggi - duduk (Max): |
6.25 mm |
Archivi Disponibil: |
PDF / 3D / ISG / Stp / Langkah / Datasheet |
| Deskripsi Paket Mfr | ROHS COMPLIANT |
| REACH Compliant | iya nih |
| EU RoHS Compliant | iya nih |
| Status | Aktif |
| Jenis Trafo | TRANSFORMATOR DATACOM |
| Aplikasi | LAN; 1000 BASE-T |
| Persetujuan | UL |
| Rugi Penyisipan | 1,0 dB |
| Tegangan Isolasi | 1500,0 V |
| Seri Produsen | 749020010A |
| Fitur Pemasangan | PERMUKAAN GUNUNG |
| Jumlah Fungsi | 4 |
| Suhu Operasi-Min | -40,0 Cel |
| Suhu Operasi-Max | 85,0 Cel |
| Metode kemasan | TAPE & REEL |
| Dimensi Fisik | L17.5XB14.20XH6.50 (mm) |
| Induktansi Primer | 350,0 µH |
| Sub Kategori | Transformer Lainnya |
| Ternyata Rasio (Np: Ns) | 1: 1; 1: 1 |
| Tinggi | 6,5 mm |
| Panjangnya | 17,5 mm |
| Lebar | 14,2 mm |
| Fitur Tambahan | HEIGHT DIMENSION MENCAKUP TERMINAL JUGA |
