Rincian Produk
Tempat asal: Guangdong, Cina
Nama merek: LINK-PP
Sertifikasi: UL,RoHS,Reach,ISO
Nomor model: 7497111611A
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 50/500/1000/60K
Harga: $0.11-$24
Kemasan rincian: BAKI
Waktu pengiriman: persediaan
Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day
Menyediakan kemampuan: 180K/Bulan
SPEC: |
7497111611A |
Bergantian: |
LPJU4281A64NL |
Munafactuer asli: |
LINK-PP |
Aplikasi: |
10/100/1000 Basis-t |
Penghentian: |
Pateri |
LED: |
Opsional |
File: |
Langkah 3D IGS PDF |
Rf silang: |
LPJU4281A64NL = 7497111611A |
SPEC: |
7497111611A |
Bergantian: |
LPJU4281A64NL |
Munafactuer asli: |
LINK-PP |
Aplikasi: |
10/100/1000 Basis-t |
Penghentian: |
Pateri |
LED: |
Opsional |
File: |
Langkah 3D IGS PDF |
Rf silang: |
LPJU4281A64NL = 7497111611A |
| Turn Ratio ((± 2%): | TX=1CT:1CT RX=1CT:CT |
| Induktansi OCL | 350uH MIN/@ 100KHz,0.1V,8mA DC Bias |
| Kerugian Penempatan | -1.0dB MAX @ 1-65MHz |
| Kembali Kerugian | -20dB MIN @ 1-10MHz |
| -16dB MIN @ 10-30MHz | |
| -12dB MIN @ 30-60MHz | |
| -10dB MIN @ 60-100MHz | |
| Bicara silang | -40dB MIN @ 1-30MHz |
| -35dB MIN @ 30-60MHz | |
| -30dB MIN @ 60-100MHz | |
| Penolakan Mode Umum | -30dB MIN @ 1-50MHz |
| -20dB MIN @ 50-150MHz | |
| Tes Hipot | 1500Vrms MIN |
| Jangkauan suhu operasi | 0°C sampai 70°C. |
