Rincian Produk
Tempat asal: Guangdong, Cina
Nama merek: LINK-PP
Sertifikasi: UL,RoHS,Reach,ISO
Nomor model: 749013011A
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 400/2000/10k/25k
Harga: $0.06-$0.9
Kemasan rincian: T & r
Waktu pengiriman: 3-5 hari
Syarat-syarat pembayaran: TT, Net30/60/90 hari
Menyediakan kemampuan: 3kk/bulan
Nomor bagian: |
749013011A |
Kategori: |
Transformator LAN / Magnet Ethernet |
Jenis pemasangan: |
Surface Mount (SMT) |
Laju data: |
10/100BASE-TX |
Dukungan POE: |
Ya |
Suhu operasi: |
-40 ° C hingga +105 ° C |
Nomor bagian: |
749013011A |
Kategori: |
Transformator LAN / Magnet Ethernet |
Jenis pemasangan: |
Surface Mount (SMT) |
Laju data: |
10/100BASE-TX |
Dukungan POE: |
Ya |
Suhu operasi: |
-40 ° C hingga +105 ° C |
The 749013011A is a high-performance LAN transformer specifically designed for 10/100 Base-T Ethernet applications with Power over Ethernet (PoE) support. This SMT transformer provides signal integrity, electrical isolation, and efficient power transfer over Ethernet cables, fully compliant with IEEE 802.3 and IEEE 802.3af standards.
It is ideal for industrial automation, IP communication, and IoT applications where reliable Ethernet connectivity and PoE power delivery are required.
|
|---|
The 749013011A supports PoE operation with up to 350 mA current per center tap, allowing both data transmission and DC power delivery through a single Ethernet cable.
It is optimized for thermal reliability — ensuring stable performance up to +105°C component temperature under full PoE load.
