Rincian Produk
Tempat asal: Guangdong, Cina
Nama merek: LINK-PP
Sertifikasi: UL,RoHS,Reach,ISO
Nomor model: TLA-8T104WLF-T
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 400/2000/10k/25k
Harga: $0.08-$1.2
Kemasan rincian: T & r
Waktu pengiriman: di kapal stok hari ini
Syarat-syarat pembayaran: TT, Net30/60/90 hari
Menyediakan kemampuan: 3kk/bulan
Nomor bagian: |
TLA-8T104WLF-T |
Jenis Produk: |
Transformer Ethernet |
Induktansi: |
350 μH |
Turn Rasio: |
1ct: 1ct |
Tegangan isolasi: |
1500Vrms |
Kisaran suhu operasi: |
-40 ° C hingga +85 ° C. |
Nomor bagian: |
TLA-8T104WLF-T |
Jenis Produk: |
Transformer Ethernet |
Induktansi: |
350 μH |
Turn Rasio: |
1ct: 1ct |
Tegangan isolasi: |
1500Vrms |
Kisaran suhu operasi: |
-40 ° C hingga +85 ° C. |
The TDK TLA-8T104WLF-T is a high-performance SMT transformer module designed for LAN 10G Base-T applications. Engineered specifically for automotive electronic systems, it ensures reliable high-speed data transmission while meeting the stringent AEC-Q200 qualification standard. With excellent isolation, low insertion loss, and compact dimensions, this module is ideal for next-generation automotive Ethernet networks and other demanding high-speed communication environments.
| Parameter | Specification |
|---|---|
| Type | LAN 10G Base-T Pulse Transformer |
| Inductance | 350 µH (100 kHz, 8 mA DC bias) |
| Turns Ratio | 1CT:1CT (TX and RX channels) |
| Insertion Loss | ≤ 1 dB (0.1 - 100 MHz) |
| Interwinding Capacitance | ≤ 30 pF |
| Isolation Voltage | 1500 Vrms, 50 Hz, for 1 minute |
| Operating Temperature | -40°C to +85°C |
| Package Type | Surface-mount, 11.60 × 6.50 × 5.90 mm |
| Packaging | Tape & reel (1000 pcs per reel) |
| Compliance | RoHS and REACH SVHC-Free |
