Rincian Produk
Place of Origin: China
Nama merek: LINK-PP
Sertifikasi: ROHS,Reach
Model Number: 1-1840860-2
Ketentuan Pembayaran & Pengiriman
Minimum Order Quantity: 50pcs
Harga: $0.09-$2.3
Packaging Details: Tape and Reel (1 Reel = 350pcs)
Delivery Time: Ships within 1-2 weeks
Payment Terms: TT, NET30/60/90 Days
Supply Ability: 6.5million-PCS/Month
Number of Channels/Ports: |
2x6 |
Mounting Style: |
Through Hole Mount |
PoE Rating: |
Non-PoE |
Data Rate: |
Gigabit |
Size: |
41.20 x 87.01 x 25.50mm |
Isolation Voltage: |
2250VDC |
Number of Channels/Ports: |
2x6 |
Mounting Style: |
Through Hole Mount |
PoE Rating: |
Non-PoE |
Data Rate: |
Gigabit |
Size: |
41.20 x 87.01 x 25.50mm |
Isolation Voltage: |
2250VDC |
| Item/Nomor Part | 1-1840860-2 MagJack |
|---|---|
| Rasio Lilitan | 1:1 Keempat pasang |
| Induktansi sisi media | 350uH min @100KHz, 0.1VRMS, bias DC 8mA |
| Insertion Loss | - 1.1dB maks dari 1.0MHz hingga 100MHz |
| Return Loss |
- 18dB min dari 1.0MHz hingga 40MHz; |
| Redaman Crosstalk | - 35dB min dari 1.0MHz hingga 40MHz; - 33-20LOG(f/50)dB min dari 40.1MHz hingga 100MHz |
| Tegangan Isolasi | 2250VDC (maks) selama 60 detik dengan waktu naik 500V/detik |
| Suhu Operasi | 0°C - +70°C |
| Rasio Penolakan Mode Umum (CMRR) | - 30dB min dari 1.0MHz hingga 100MHz |
• Server atau kartu blade
• Kartu Antarmuka Jaringan
• Komputer laptop
• Sistem penyimpanan
• Kartu Mezzanine
