Rincian Produk
Tempat asal: Guangdong, Cina
Nama merek: LINK-PP
Sertifikasi: UL,ROHS,Reach,ISO
Nomor model: HR901110A
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 50/500/1000
Harga: 0.68-0.92 USD/PCS
Kemasan rincian: Paket: 60 PC di nampan 1, 22 nampan dalam 1 karton yang 37 * 30 * 30 cm, 10 kg (1320 pcs) dari setia
Waktu pengiriman: persediaan
Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day
Menyediakan kemampuan: 3000000/bulan
Nomor bagian: |
HR901110A |
Lintas & Lembar Data: |
LPJ0012DNL |
Aplikasi: |
10/100 Base-T |
Munafactuer asli: |
LINK-PP |
Aplikasi Proyek: |
Kartu Antarmuka Jaringan |
Mengajukan: |
PDF / 3D / ISG / Stp / Langkah / Lembar Data |
Nomor bagian: |
HR901110A |
Lintas & Lembar Data: |
LPJ0012DNL |
Aplikasi: |
10/100 Base-T |
Munafactuer asli: |
LINK-PP |
Aplikasi Proyek: |
Kartu Antarmuka Jaringan |
Mengajukan: |
PDF / 3D / ISG / Stp / Langkah / Lembar Data |
| Single Port RJ45 PCB Modular Jack dengan 10/100 Base-T Integrated Magnetics, Tanpa LED, Tab Bawah, RoHS | |
| Nomor Bagian LINK-PP | LPJ0012DNL |
| Aplikasi-Lan | ETHERNET (NoN PoE) |
| AutomDX | IYA NIH |
| Bst Circuit | IYA NIH |
| Konfigurasi RX | T, C |
| Konfigurasi TX | T, C |
| Hubungi Plating Area Perkawinan | EMAS 6u "/ 15u" / 30u " |
| Cores per Port | 4 |
| Dioda | TIDAK ADA DIODA |
| Opsi LED | TANPA LED |
| Memalangi | TAB BAWAH |
| Jumlah Port | 1X1 |
| PCB | FR4 |
| PCB Mount Angle | SIDE ENTRY |
| PCB Mempertahankan Posting | T POST |
| Paket Tinggi (Inci) | 0,528 |
| Tinggi Paket (mm) | 13,40 |
| Paket Panjang (Inci) | 0,839 |
| Paket Panjang (mm) | 21.30 |
| Paket Lebar (Inci) | 0,626 |
| Lebar Paket (mm) | 15,90 |
| Pin Type | THT SOLDER |
| RoHS Compliant | YA-ROHS-5 DENGAN MEMIMPIN DI PEMERIKSAAN SOLDER |
| Pencarian | IYA NIH |
| Perisai Tab EMI | TANPA |
| Kecepatan | 10/100 BASE-T |
| Suhu | - 40 ℃ KE + 85 ℃ |
| Ternyata Rasio RX | 1CT: 1CT |
| Ternyata Rasio TX | 1CT: 1CT |
Bagian Terkait |
| LPJ0007DNL | RJ-10437C | LPJ0026DNL | RJ-10416C |
| LPJ0009GDNL | RJ-10437B | LPJ0026G7NL | RJ-10416 |
| LPJ0011AANL | RJ-10437 | LPJ0026GANL | LPJ0011HBNL |
| LPJ0011ABNL | LPJ0017CNL | LPJ0026GDNL | LPJ0011HENL |
| LPJ0011ACNL | LPJ0017FENL | LPJ0026GENL | LPJ0012A73NL |
| LPJ0011BBNL | LPJ0017GENL | LPJ0026HDNL | LPJ0012CNL |
| LPJ0011CNL | LPJ0022BANL | LPJ0034BBNL | LPJ0012G7NL |
| LPJ0011DNL | LPJ0022BBNL | LPJ0034CNL | LPJ0012GDNL |
| LPJ0011EBNL | LPJ0022DNL | LPJ0034DNL | LPJ0012GENL |
| LPJ0011FBNL | LPJ0022FBNL | LPJ0037FBNL | LPJ0012NDNL |
| LPJ0011G4NL | LPJ0025AANL | LPJ0040DNL | LPJ0013ABNL |
| LPJ0011GBNL | LPJ0025ABNL | LPJ0044CNL | LPJ0013AHNL |
| LPJ0011GDNL | LPJ0025AGNL | LPJ0047NNL | LPJ0013BBNL |
| LPJ0011GENL | LPJ0025CNL | LPJ0049A76NL | LPJ0013BHNL |
| LPJ0011GFNL | LPJ0025DNL | LPJ0049AENL | LPJ0013CNL |
| RJ-10403 | LPJ0025FBNL | LPJ0049AZNL | LPJ0013DNL |
| LPJ0025GANL | LPJ0025G4NL | LPJ0049CNL | LPJ0013FBNL |
| LPJ0025GBNL | RJ-180G53A | LPJ0049GDNL | LPJ0013GENL |
| LPJ0025GCNL | RJ-180G53 | LPJ0050ABNL | LPJ0014A55NL |
| LPJ0025GENL | RJ-180G52B | LPJ0050BBNL | LPJ0014BBNL |
| LPJ0025HHNL | RJ-180G52A | LPJ0050CNL | LPJ0014CNL |
| LPJ0026A73NL | LPJ0026A7NL | LPJ0050DNL | LPJ0014DNL |
| RJ-180G51B | LPJ0026ABNL | LPJ0055CNL | RJ-104G54 |
| RJ-180G51A | LPJ0026BBNL | LPJ0055FBNL | RJ-101G53Y |
| RJ-180G51 | LPJ0026BCNL | LPJ0064GENL | RJ-104G53M |
| RJ-180G50A | LPJ0026CNL | LPJ0070CNL | RJ-104G50 |
| RJ-180G50 | RJ-180A01 | RJ-180A07 | RJ-10401M |
| RJ-180A08 | RJ-101F02 | RJ-180A06 | RJ-10401A |
| RJ-180A03 | RJ-101F01 | RJ-180A05 | RJ-10401 |
| RJ-180A02 | RJ-101B56 | RJ-180A03A | RJ-10449Y |
| RJ-180A01D | RJ-101B50 | RJ-10149A | RJ-10449B |
