Rincian Produk
Tempat asal: Guangdong, Cina
Nama merek: LINK-PP
Sertifikasi: UL,ROHS,Reach,ISO
Nomor model: LU1T516-43LF
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 50/500/1000/25K
Harga: $0.09-$1.85
Kemasan rincian: 50PCS / Baki, 1200pcs / Carton
Waktu pengiriman: persediaan
Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day
Menyediakan kemampuan: 250000-320000/bulan
Spesifikasi: |
LU1T516-43 JIKA |
P/N: |
LPJ0025ABNL |
Mekanis: |
21.3x16.0x11.0mm |
Aplikasi: |
10/100base-t |
Pemasangan: |
Tht |
Sampel: |
bebas |
Spesifikasi: |
LU1T516-43 JIKA |
P/N: |
LPJ0025ABNL |
Mekanis: |
21.3x16.0x11.0mm |
Aplikasi: |
10/100base-t |
Pemasangan: |
Tht |
Sampel: |
bebas |
|
Spesifikasi
|
P/N
|
Produsen
|
Deskripsi
|
|
LU1T516-43 F
|
LPJ0025ABNL
|
LINK-PP
|
Filter rj45 10/100Mbps
|
|
Seri
|
Jenis konektor
|
Aplikasi
|
Tipe pemasangan
|
| Magjack |
LINK-PP RJ45
|
10/100 Mbps
|
Melalui Lubang
|
|
LU1T516-43 LF Desain untuk transmisi 100 BASE melalui kabel UTP-5.
|
|||
|
Orientasi
|
Penghentian
|
Warna LED
|
Perisai
|
|
90° Sudut (kanan)
|
Solder
|
Hijau/kuning
|
Terlindung
|
Fitur Utama:
Bahan:
|
|||
| Parameter | Spesifikasi |
|---|---|
| Tingkat Data | 10/100 BASE-TX |
| Induktansi (OCL) | 350 μH Minimal |
| Kondisi pengujian OCL | 100KHz / 0,1V dengan bias DC 8mA diterapkan |
| Rasio berputar (± 5%) | Tx = 1CT:1 / Rx = 1CT:1CT |
| Kerugian Penempatan | -1,15 dB Max (0,3 MHz sampai 100 MHz) |
| Isolasi (HI-POT) | Minimal 1500 Vrms |
| Kapasitas perpaduan (CW/W) | 28 pF Max |
| Induktansi kebocoran (L.L) | 0.4 μH Max |
| Jangkauan Frekuensi | Kembali Kerugian |
|---|---|
| 30 MHz | -16 dB |
| 40 MHz | -14 dB |
| 50 MHz | -13,5 dB |
| 60 MHz | -13 dB |
| 80 MHz | -10 dB |
| Jangkauan Frekuensi | Cross Talk |
|---|---|
| 0.3 30 MHz | -40 dB |
| 30 ¢ 60 MHz | -35 dB |
| 60 ¢ 100 MHz | -30 dB |
| Jangkauan Frekuensi | CMR |
|---|---|
| 1 30 MHz | -30 dB |
| 30 ¢ 60 MHz | -25 dB |
| 60 125 MHz | -20 dB |
Dibangun untuk menahan siklus kawin yang sering dan kondisi operasional yang keras.
|
