Rincian Produk
Tempat asal: Guangdong, Cina
Nama merek: LINK-PP
Sertifikasi: UL,RoHS,Reach,ISO
Nomor model: XF-11FB-05ANL-SGI
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 400/2000/10K/25K
Harga: $0.06-$3.2
Kemasan rincian: T&R
Waktu pengiriman: persediaan
Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day
Menyediakan kemampuan: 3KK/Bulan
P/n: |
XF-11FB-05ANL-SGI / XF-11FB-05ANL |
Putar Radio: |
1: 1 |
Jenis: |
Smd |
Keluarga: |
Transformator 10/100Mbps |
PELABUHAN: |
Port tunggal |
Hipot: |
1500VDC |
P/n: |
XF-11FB-05ANL-SGI / XF-11FB-05ANL |
Putar Radio: |
1: 1 |
Jenis: |
Smd |
Keluarga: |
Transformator 10/100Mbps |
PELABUHAN: |
Port tunggal |
Hipot: |
1500VDC |
| Parameter | Spesifikasi |
|---|---|
| Rasio putaran (± 2%) | 1CT: 1CT |
| OCL (100KHz/100mV @8mA) | 350 μH MIN |
| Kerugian Penempatan (dB MAX) | -1,1 dB (0,3~100 MHz) |
| Kehilangan Pengembalian (dB TYP) | -20 dB (30 MHz), -14 dB (60 MHz), -11.5 dB (80 MHz) |
| Crosstalk (dB TYP) | -45 dB (30 MHz), -40 dB (60 MHz), -35 dB (100 MHz) |
| DCMR (dB TYP) | -42 dB (30 MHz), -37 dB (50 MHz), -33 dB (100 MHz) |
| Tes Hi-Pot | 1500 Vrms/0.5mA/60 detik atau 1650 Vrms/0.5mA/2 detik |
| Suhu operasi | -40°C sampai +85°C |
| Kepatuhan RoHS | Ya. |
