Rincian Produk
Tempat asal: Cina
Nama merek: LINK-PP
Sertifikasi: UL,ROHS,Reach,ISO
Nomor model: SI-60153-F
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 50/500/1000/25K
Harga: $0.05-$1.28
Kemasan rincian: 50PCS / Baki, 1200pcs / Carton
Waktu pengiriman: persediaan
Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day
Menyediakan kemampuan: 4200K-PCS / Bulan
Nomor bagian: |
SI-60153-F |
Lintas: |
LPJ4077CNL |
Produsen: |
LINK-PP |
Grendel: |
Tab bawah |
Sampel: |
Tersedia 1-5 Pcs |
Mengajukan: |
PDF / 3D / ISG / Stp / Langkah / Lembar Data |
Nomor bagian: |
SI-60153-F |
Lintas: |
LPJ4077CNL |
Produsen: |
LINK-PP |
Grendel: |
Tab bawah |
Sampel: |
Tersedia 1-5 Pcs |
Mengajukan: |
PDF / 3D / ISG / Stp / Langkah / Lembar Data |
| LINK-PP Part Number | LPJ4077CNL |
| Part Number | SI-60153-F |
| Application-Lan | ETHERNET(NoN PoE) |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Diodes | NO DIODES |
| LED Option | WITHOUT |
| Latch | TAB DOWN |
| Number of Ports | 1X1 |
| PCB Mount Angle | SIDE ENTRY |
| Package Height (mm) | 13.30 |
| Package Length (mm) | 21.25 |
| Package Width (mm) | 15.93 |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Search | YES |
| Shield EMI Tabs | WITH |
| Speed | WITHOUT |
| Temperature | -40 TO + 80℃ |
| Turns Ratio RX | 1CT:1CT |
| Turns Ratio TX | 1CT:1CT |
LINK-PP Is The Preferred Designer and Manufacturer of TI, LINK-PP PN: LPJ001BBNL Was Used In BeagleBone Board. Welcome to visit the Texas Instruments's websit:www.ti.com,you will look at our logo "LINK-PP" on BeagleBone Board.
Successful Customer:
• Texas Instruments
LINK-PP is the preferred supplier of TI.
Welcome to visit the TI website: http://www.ti.com/tool/beaglebk#0
You will look at our logo "LINK-PP" on BeagleBone Board.
• Intel
LINK-PP Is the preferred supplier of Intel.
LINK-PP LPJG16314A4NL is used in MinnowBoard max of Intel.
• Cisco
LINK-PP Is the preferred supplier of Cisco.
LINK-PP LPJ0011DNL is used in gate way of Cisco. Jabil is the OEM for this project.
Applications For Terminal User
Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem,Call Center solutions , Complex set top boxes , VOIP gateways setup,Border Gateway Protocol,fast ethernet switch ...
Main Customer
Design for Ti , Intel , Samsung , Fluke , Jabil , Flextronics ,Cypress, Freescale,EKF.......
EMS Application
Built-in Flexible PCB Assembly; Rigid-Flexible PCB Assembly; Microelectronic, Flip Chip; Microelectronic, Chip On Board; Optoelectronic Assembly; RF / Wireless Assembly; Through Hole Assembly; Surface Mount Assembly; System Assembly; Printed Circuit Board Assembly
LINK-PP RJ45 Designed for BeagleBone Black of Texas Instrument
http://www.ti.com/tool/beaglebk#0
a low-cost, open source, community-supported development platform for ARM® Cortex™-A8 processor developers and hobbyists.
