Product Details
Tempat asal: Cina
Nama merek: LINK-PP
Sertifikasi: UL,ROHS,Reach,ISO
Nomor model: J00-0045NL
Payment & Shipping Terms
Kuantitas min Order: 50/500/1000
Harga: Supportive
Kemasan rincian: 50PCS / Baki, 1200pcs / Carton
Waktu pengiriman: persediaan
Syarat-syarat pembayaran: TT,NET30/60/90 Hari Day
Menyediakan kemampuan: 4600K. PCS/bulan
Nomor bagian: |
J00-0045NL |
Perisai: |
Terlindung |
Buatan China: |
LINK-PP |
Aplikasi: |
AutoMDIX 10/100 Base-TX |
Keluarga: |
Jacks With Magnetics |
Mass Cross: |
LPJ4011BBNL |
Orientasi: |
Sudut 90 ° (kanan) |
Warna LED: |
Hijau kuning |
Nomor bagian: |
J00-0045NL |
Perisai: |
Terlindung |
Buatan China: |
LINK-PP |
Aplikasi: |
AutoMDIX 10/100 Base-TX |
Keluarga: |
Jacks With Magnetics |
Mass Cross: |
LPJ4011BBNL |
Orientasi: |
Sudut 90 ° (kanan) |
Warna LED: |
Hijau kuning |
| Semua harga dalam dolar AS. | ||||||||||||||||||||||||||||||||
| Nomor Bagian Pedagang | J00-0045NL PulseJack |
| ||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pabrikan | Pusle | |||||||||||||||||||||||||||||||
| Produsen PN | J00-0045NL | |||||||||||||||||||||||||||||||
| Deskripsi | CONN MAGJACK 1PORT 100 BASE-TX | |||||||||||||||||||||||||||||||
| Status Bebas Timbal / Status RoHS | Bebas timah / Sesuai RoHS | |||||||||||||||||||||||||||||||
| LINK-PP China Factory Cross | LPJ4011BBNL Buatan China | |||||||||||||||||||||||||||||||
| LPJ4011BBNLKuantitas Tersedia | 60.000 PCS | |||||||||||||||||||||||||||||||
LINK-PP Buatan China, Daftar Produksi Massal Pabrik:
| J00-0045NL | SI-60182-F | 13F-64YGD2PLNW2NL | 99751805-01 |
| 99751813-01 | 13F-611GYDP2NL | XFATM2GA-CLGY1-2MS | XFATM6CB-CLYG1-4MS |
| JX0011D21BNL | J00-0045NL | MTJ-88TX1-FSZ-PG-D1LH-M7 | RJ-035TAI |
| RJLD260TC1 | SI-60118-F | HFJ11-E2450E-L12RL | 6605468-4 |
| RJLD-260TC1 | J1B1211CFD | XFATM2E-Clxu1-4MS | 7499211121A |
| 213A-11XAX-R | RJC-248TC1 | J00-0076 | MIC66011-5171T-LF3 |
| JXR0-0015NL | RJLBC-060TC1 | J00-0045NL | XFO656P-CLxu1-4MS |
| 13F-64HND2NL | HY911105AE | 5-1840450-7 | 24F-2011EGYD2SNWXNL |
| HFJ11-E2450E-RL | 2-1840450-8 | HFJ11-E2450E-L11RL | 5-6605443-1 |
| SJTAB-40LB02-L | RJLB-001TC1 | 13F-64GYDPNS2NL | XFAMT6SA-CLGY1-4MS |
| 3070-110204 | J00-0045NL | RJ-032TC | 24G-66JGYDPLZ2NL |
| J00-0045NL | 74990112121 | J00-0045NL | RJLB-001TC1 |
J00-0045NL SPESFIKASI LISTRIK: @ 25 ℃
1.Rasio Putar (± 2%):
TX = 1CT: 1 RX = 1CT: 1
2. Induktansi OCL:
350uH MIN @ 100KHz 0.1V 8mA DC Bias
3. Rugi Insersi:
-1.0dB MAKS @ 1.0-100MHz
4. Rugi Kembali:
-18dB MIN @ 1-30MHz -15dB MIN @ 30-60MHz -12dB MIN @ 60-80MHz -10dB MIN @ 80-100MHz
5. Bicara silang:
-40dB MIN @ 30MHz -35dB MIN @ 60MHz -30dB MIN @ 100MHz
6. Penolakan Mode Umum:
-40dB MIN @ 30MHz -35dB MIN @ 60MHz -30dB MIN @ 100MHz
7. Hipot: 1500Vrms
8. Lampu LED:
Panjang Gelombang: HIJAU / KUNING: 570nm / 590nm Tegangan Maju (Vf): 1.8V-2.6V (Kondisi Uji: 20mA)
9. Rentang Suhu Operasi: -40 ℃ TO + 85 ℃
